Mainboard|MSI|AMD X870|SAM5|ATX|Memory DDR5|Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 4x|1xPCI-Express 5.0 16x|3xM.2|1xHDMI|4xUSB 2.0|3xUSB 3.2|2xUSB-C|1xRJ45|3xAudio port|PROX870-PWIFI

PRO X870-P WIFI - Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
- Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
- Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr II are built for high performance system and non-stop experience
- EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
- Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience

Description

PRO X870-P WIFI - Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
- Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
- Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr II are built for high performance system and non-stop experience
- EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
- Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience

Vendor Homepage

www.msi.com/Motherboard/PRO-X870-P-WIFI

Model

PRO X870-P WIFI

Chipset

AMD X870

Socket

SAM5

Form Factor

ATX

Memory type

DDR5

Frequency speed

4800/5000/5200/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600/7800/8000/8200 MHz

Memory slots

4

M.2

3

PCI-Express 3.0 1x

2

PCI-Express 4.0 4x

1

PCI-Express 5.0 16x

1

Audio port

3

HDMI

1

RJ45

1

USB 2.0

Yes

USB 3.2

Yes

USB-C

Yes

Bluetooth

Yes

WiFi

Yes

Integrated video

Depending on CPU

Integrated audio

Realtek ALC897

Integrated LAN

5 Gigabit

RAID

SATA 0, 1

TPM

Header

Units per Shipping Box

5

Shipping Box Depth

38 cm

Shipping Box Height

37 cm

Shipping Box Weight

10.35 kg

Shipping Box Width

28.5 cm

Unit Calculated Volume

0.008014 cubm

Product Net Weight

1.5 kg

Unit Calculated Weight

2.07 kg

Unit Box Width

0.27

Unit Box Length

0.345

Unit Box Height

0.07

Full Description Line

AMD X870|SAM5|ATX|DDR5|8200/8000/7800/7600/7400/7200/7000/6800/6600/6400/6200/6000/5800/5600/5200/5000/4800 MHz|Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 4x |1xPCI-Express 5.0 16x|3xM.2|1xHDMI|4xUSB 2.0|3xUSB 3.2|2xUSB-C|1xRJ45|3xAudio port|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|Video Depending on CPU|Audio Realtek ALC897|LAN 5 Gigabit|RAID SATA 0, 1|TPM Header

Category Code

MBA
