NET CAMERA 5MP IR BULLET AI/HFW5541T-ASE-0360B-S3 DAHUA

1/2.7” 5Megapixel progressive scan CMOS, 2960 × 1668 @30FPS

Minimum illumination: 0.0009 Lux @ F1.6 (Color,30IRE); 0.0005 Lux @ F1.6 (B/W,30IRE); 0 lux (Illuminator on)

True Day/Night with ICR Filter, BLC / HLC / True WDR (120dB), 3D DNR, Defog

3.6 mm fixed lens (92°)

Up to 80 meters Smart IR Illumination

H.265+, H.265, H.264+, H.264, H.264B, H.264H, MJPEG, ONVIF (Profile S/Profile G/Profile T); CGI

Micro SD: Max 512GB, 1/1 Audio I/O, 1/1 Alarm I/O

With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

Bullet design, metal shell, IP67, IK10, -40°C~+60°C

Power ePoE / PoE / 12VDC power, 9.8W max

Free IP monitoring software available

Description

1/2.7” 5Megapixel progressive scan CMOS, 2960 × 1668 @30FPS

Minimum illumination: 0.0009 Lux @ F1.6 (Color,30IRE); 0.0005 Lux @ F1.6 (B/W,30IRE); 0 lux (Illuminator on)

True Day/Night with ICR Filter, BLC / HLC / True WDR (120dB), 3D DNR, Defog

3.6 mm fixed lens (92°)

Up to 80 meters Smart IR Illumination

H.265+, H.265, H.264+, H.264, H.264B, H.264H, MJPEG, ONVIF (Profile S/Profile G/Profile T); CGI

Micro SD: Max 512GB, 1/1 Audio I/O, 1/1 Alarm I/O

With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

Bullet design, metal shell, IP67, IK10, -40°C~+60°C

Power ePoE / PoE / 12VDC power, 9.8W max

Free IP monitoring software available

Vendor Homepage

www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HFW5541T-ASE-S3=S3

Model

IPC-HFW5541T-ASE-0360B-S3

Camera design

Bullet

Network Camera Type

HDTV/Megapixel/Outdoor

Pixel Resolution

5 Mega Pixel

Focal Length

3.6 mm

IR Illumination

Yes

Sensor size

1/2.7”

Microphone

Built-in

Lens Mount

M12

Min. Illumination

0.0009 Lux

Effective pixels

2960 (H) × 1668 (V)

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Alarm In

1

Alarm Out

1

Audio-In

1

Audio-Out

1

RJ45

1

Supports card capacities up to

512GB

Power options

12V/PoE

Power supply requirements

12 VDC/PoE (802.3af)/ePoE

Power consumption

9.8 Watts

Environment

Outdoor

Operating temperature range

-40°C~+60°C

Colour

White

Dimensions

244.1 × 79.0 × 75.9 mm

Units per Shipping Box

10

Shipping Box Depth

58 cm

Shipping Box Height

26 cm

Shipping Box Weight

13.2 kg

Shipping Box Width

31 cm

Unit Calculated Volume

0.004675 cubm

Product Net Weight

0.82 kg

Unit Calculated Weight

1.32 kg

Unit Box Width

0.12

Unit Box Length

0.3

Unit Box Height

0.11

Full Description Line

Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 3.6 mm|IR Illumination|Sensor size 1/2.7”|Microphone Built-in|Lens Mount M12|Min. Illumination 0.0009 Lux|Effective pixels 2960 (H) × 1668 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 512GB|Power options PoE/12V|Power supply requirements 12 VDC/PoE (802.3af)/ePoE|Environment Outdoor|Operating temperature range -40°C~+60°C|Colour White|Dimensions 244.1 × 79.0 × 75.9 mm

Category Code

FNC
