CASE FAN 80MM P8 MAX/ACFAN00286A ARCTIC

P8 Max

80 mm High Speed PWM Fan


The P8 Max is a powerful fan with 500 to 5000 rpm.The fan delivers a static pressure of 5.3 mmH2O and generates an airflow of up to 40 cfm. It offers precise control of the fan speed via pulse width modulation (PWM) and is extremely efficient at 0.19 A. The P8 Max is ideal for 2U server racks, which often require a high airflow to effectively dissipate heat. In addition, it has a 0 dB mode for silent operation in IDLE.

Description

P8 Max

80 mm High Speed PWM Fan


The P8 Max is a powerful fan with 500 to 5000 rpm.The fan delivers a static pressure of 5.3 mmH2O and generates an airflow of up to 40 cfm. It offers precise control of the fan speed via pulse width modulation (PWM) and is extremely efficient at 0.19 A. The P8 Max is ideal for 2U server racks, which often require a high airflow to effectively dissipate heat. In addition, it has a 0 dB mode for silent operation in IDLE.

Vendor Homepage

www.arctic.de/en/P8-Max/ACFAN00286A

Model

ACFAN00286A

Model name

P8 Max

Fan size group

80mm

Bearing type

Ball

Number of fans

1

Nominal voltage

12 V

Fan speed

500–5000 rpm

Air flow

40 cfm

Mainboard connection

4-pin

Colour

Black

Dimensions

80x80x25mm

Units per Shipping Box

150

Shipping Box Depth

44 cm

Shipping Box Height

30 cm

Shipping Box Weight

15.8 kg

Shipping Box Width

27 cm

Unit Calculated Volume

0.0002376 cubm

Product Net Weight

0.084 kg

Unit Calculated Weight

0.105 kg

CnCode

84145925

Unit Box Width

0.085

Unit Box Length

0.085

Unit Box Height

0.03

Full Description Line

P8 Max|Number of fans 1|Nominal voltage 12 V|Air flow 40 cfm|Colour Black|Dimensions 80x80x25mm

Category Code

COS
