Mainboard|ASROCK|AMD B850|SAM5|Micro-ATX|Memory DDR5|Memory slots 4|4xPCI-Express 4.0 4x|1xPCI-Express 5.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|3xUSB 3.2|1xUSB-C|1xRJ45|B850MSTEELLEGENDWIFI

Steel Legend represents the philosophical state of rock-solid durability and irresistible aesthetics. Built around most demanding specs and features, the Steel Legend series aims at daily users and mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable and reliable performance.

Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors

12+2+1 Phase Power Design, Dr.MOS for VCore+SOC+MISC

4 x DDR5 DIMMs

Supports Dual Channel, up to 8000+ (OC)

1 PCIe 5.0 x16, 1 PCIe 4.0 x4

Graphics Output Options: 1 HDMI, 1 DisplayPort

Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio

1 Blazing M.2 (PCIe Gen5x4)

1 Hyper M.2 (PCIe Gen4x4)

1 M.2 (PCIe Gen4x2)

4 SATA3

2 USB 3.2 Gen2 Type-A+C (Rear)

1 USB 3.2 Gen1 Type-C (Front)

6 USB 3.2 Gen1 (2 Rear, 4 Front)

8 USB 2.0 (4 Rear, 4 Front)

Realtek 2.5G LAN

802.11be WiFi 7 +Bluetooth

Supports M.2 Bottom Heatsink, BIOS Flashback

Description

Steel Legend represents the philosophical state of rock-solid durability and irresistible aesthetics. Built around most demanding specs and features, the Steel Legend series aims at daily users and mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable and reliable performance.

Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors

12+2+1 Phase Power Design, Dr.MOS for VCore+SOC+MISC

4 x DDR5 DIMMs

Supports Dual Channel, up to 8000+ (OC)

1 PCIe 5.0 x16, 1 PCIe 4.0 x4

Graphics Output Options: 1 HDMI, 1 DisplayPort

Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio

1 Blazing M.2 (PCIe Gen5x4)

1 Hyper M.2 (PCIe Gen4x4)

1 M.2 (PCIe Gen4x2)

4 SATA3

2 USB 3.2 Gen2 Type-A+C (Rear)

1 USB 3.2 Gen1 Type-C (Front)

6 USB 3.2 Gen1 (2 Rear, 4 Front)

8 USB 2.0 (4 Rear, 4 Front)

Realtek 2.5G LAN

802.11be WiFi 7 +Bluetooth

Supports M.2 Bottom Heatsink, BIOS Flashback

Vendor Homepage

www.asrock.com/mb/AMD/B850M%20Steel%20Legend%20WiFi/index.asp#Overview

Category Code

MBA

Unit Box Height

0.06

Unit Box Length

0.3

Unit Box Width

0.265

M.2

1

PCI-Express 4.0 4x

4

PCI-Express 5.0 16x

1

RJ45

1

USB 3.2

Да

USB тип C

1

Аудио вход

1

Аудио выход

1

Выход DisplayPort

1

Выход HDMI

1

Микрофон

1

Наличие USB 2.0

Да

Bluetooth

Да

USB-C

Да

Наличие SATA

Да

Наличие SATA 3.0

Да

Наличие WiFi

Да

Модель

B850M Steel Legend WiFi

Чипсет

AMD B850

Socket

SAM5

Форм-фактор

Micro-ATX

Тип оперативной памяти

DDR5

Частота работы оперативной памяти

8000 МГц

Количество слотов памяти

4 слота

Встроенная видео карта

Depending on CPU

Встроенная звуковая карта

Realtek ALC1220

Встроенный сетевой адаптер

2.5 Gigabit

RAID

SATA 0, 1, 10

TPM

Header

Количество в транспортной упаковке

10

Объем

0.005406 м3

Вес без упаковки

1.4 кг

Вес в упаковке

1.61 кг
