NET CAMERA 4MP IR BULLET WIFI/IPC-HFW1430DS-SAW-0280B DAHUA

1/3” 4 Megapixel progressive CMOS, 2560 × 1440 @20 fps

2.8 mm fixed lens (90 °)

Min. Illumination: 0.025 lux@ F2.0 (Color,30 IRE); 0.0025 lux@ F2.0 (B/W,30 IRE); 0 lux (Illuminator on)

Up to 30 meters IR Illumination

True Day/Night with ICR Filter, BLC, HLC, DWDR, 3D DNR

Smart H.265+; Smart H.264+, H.264B; H.264; H.264H; H.265, ONVIF (Profile S/Profile G); CGI; P2P

Wi-Fi: IEEE802.11b/g/n 2.4~2.4835GHz, up to 80 m

Built-in MIC, Micro SD Slot (up to 256 GB)

DC 12V1A Power supply, Power Consumption: < 4.1W

Bullet design, metal case, IP67, -40°C to +50°C, indoor/outdoor use

Free IP monitoring software available

Description

1/3” 4 Megapixel progressive CMOS, 2560 × 1440 @20 fps

2.8 mm fixed lens (90 °)

Min. Illumination: 0.025 lux@ F2.0 (Color,30 IRE); 0.0025 lux@ F2.0 (B/W,30 IRE); 0 lux (Illuminator on)

Up to 30 meters IR Illumination

True Day/Night with ICR Filter, BLC, HLC, DWDR, 3D DNR

Smart H.265+; Smart H.264+, H.264B; H.264; H.264H; H.265, ONVIF (Profile S/Profile G); CGI; P2P

Wi-Fi: IEEE802.11b/g/n 2.4~2.4835GHz, up to 80 m

Built-in MIC, Micro SD Slot (up to 256 GB)

DC 12V1A Power supply, Power Consumption: < 4.1W

Bullet design, metal case, IP67, -40°C to +50°C, indoor/outdoor use

Free IP monitoring software available

Vendor Homepage

https://www.dahuasecurity.com/ea/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/4MP/IPC-HFW1430DS-SAW

Camera design

Bullet

Network Camera Type

HDTV/Megapixel/Outdoor

Pixel Resolution

4 Mega Pixel

Focal Length

2.8 mm

IR Illumination

Yes

Sensor size

1/3”

Microphone

Built-in

Lens Mount

M12

Effective pixels

2560(H)×1440(V)

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

MicroSD Card Slot

1

Power options

12V

Power supply requirements

12 VDC

Operating temperature range

–40 °C to +60 °C

Dimensions

166.2 mm × 70.0 mm × 128.6 mm

Units per Shipping Box

1

Shipping Box Depth

23.5 cm

Shipping Box Height

10.5 cm

Shipping Box Weight

0.73 kg

Shipping Box Width

12.5 cm

Unit Calculated Volume

0.003084 cubm

Product Net Weight

0.477 kg

Unit Calculated Weight

0.73 kg

Unit Box Width

0.125

Unit Box Length

0.235

Unit Box Height

0.105

Full Description Line

Type HDTV/Megapixel/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/3”|Microphone Built-in|Lens Mount M12|Effective pixels 2560(H)×1440(V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xMicroSD Card Slot|Power options 12V|Power supply requirements 12 VDC|Operating temperature range –40 °C to +60 °C|Dimensions 166.2 mm × 70.0 mm × 128.6 mm

Category Code

FNC
