NET VIDEO RECORDER 4CH/NVR4104HS-4KS3 DAHUA

4CH Compact 1U 1HDD Lite Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 8 × 1080p@30 fps or 4 × 4 MP@30 fps.
> Max. 80/80/60 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 12 MP.
> AI by Recorder supports 4-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map.
> Supports EPTZ, and one-click arming and disarming.

Description

4CH Compact 1U 1HDD Lite Network Video Recorder
> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
> Max. decoding capability: 8 × 1080p@30 fps or 4 × 4 MP@30 fps.
> Max. 80/80/60 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 12 MP.
> AI by Recorder supports 4-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map.
> Supports EPTZ, and one-click arming and disarming.

Vendor Homepage

www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/Lite-Series/NVR4-4KS3-Series/1HDD/NVR4104HS-4KS3

Number of Channels

4

Number of drives/bays

1

Desktop/pedestal

Yes

Rack

Yes

CPU

Industrial-grade processor

SATA

Yes

Integrated LAN

10/100

15pin D-sub

1

Audio-In

1

Audio-Out

1

HDMI

1

RJ45

1

USB 2.0

2

Power supply requirements

12 VDC, 2 A

Power consumption

10 Watts

Dimensions

260.0 × 232.5 × 47.6 mm

Operating temperature range

–10 °C to +55 °C

Units per Shipping Box

1

Shipping Box Depth

34 cm

Shipping Box Height

31 cm

Shipping Box Weight

1.452 kg

Shipping Box Width

9 cm

Unit Calculated Volume

0.009486 cubm

Product Net Weight

0.81 kg

Unit Calculated Weight

1.45 kg

Unit Box Width

0.09

Unit Box Length

0.34

Unit Box Height

0.31

Full Description Line

Channels 4|Drives/bays 1|Desktop/pedestal|Rack|CPU Industrial-grade processor|SATA|Integrated LAN 10/100|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|Power supply requirements 12 VDC, 2 A|Power consumption 10 Watts|Dim. 260.0 × 232.5 × 47.6 mm|Temp. range –10 °C to +55 °C

Category Code

NVR
