Switch|DAHUA|Type L2|Desktop/pedestal|Rack|PoE ports 16|CS4218-16ET-135

CS4218-16ET-135

18-Port Cloud Managed Desktop Switch with 16-Port PoE

> Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards.
> Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards.
> Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE.
> A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof.

Description

CS4218-16ET-135

18-Port Cloud Managed Desktop Switch with 16-Port PoE

> Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards.
> Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards.
> Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE.
> A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof.

Vendor Homepage

transmission.dahuasecurity.com/en/product-list/Business/CloudManagementSolution/NetworkSwitch/CS4218-16ET-135

Model

CS4218-16ET-135

Switch type

L2

Desktop/pedestal

Yes

Rack

Yes

Primary port count

18

10/100M

16

Combo 10/100/1000M-T/SFP

2

IEEE 802.3

Yes

IEEE 802.3ab

Yes

IEEE 802.3af

Yes

IEEE 802.3at

Yes

IEEE 802.3u

Yes

IEEE 802.3x

Yes

IEEE 802.3z

Yes

PoE ports

16

DHCP

Yes

Switching capacity

7.2 Gbps

Forwarding rate

5.36 Mpps

Dimensions

440 mm × 220 mm × 44 mm

Units per Shipping Box

1

Shipping Box Depth

54 cm

Shipping Box Height

9 cm

Shipping Box Weight

3.08 kg

Shipping Box Width

34.5 cm

Unit Calculated Volume

0.01677 cubm

Product Net Weight

2.23 kg

Unit Calculated Weight

3.08 kg

Unit Box Width

0.345

Unit Box Length

0.54

Unit Box Height

0.09

Full Description Line

Type L2|Desktop/pedestal|Rack|16x10/100M|2xCombo 10/100/1000M-T/SFP|IEEE 802.3|IEEE 802.3ab|IEEE 802.3af|IEEE 802.3at|IEEE 802.3u|IEEE 802.3x|IEEE 802.3z|PoE ports 16|DHCP|Switching capacity 7.2 Gbps|Forwarding rate 5.36 Mpps|Dimensions 440 mm × 220 mm × 44 mm|Product Net Weight 2.23 kg

Category Code

SWI
